Product Characteristics
The bass is driven by a 38.5mm voice coil ferrite driver.
The driver adopts ferrite magnetic steel with high stability, high temperature resistance, and slow demagnetization effect.
The box adopts precise CNC machining combined with slot wedge connection technology to be sturdy and firm.
Parameter
System type: Single 5′Full Range Speaker；
Drivers: HF: 1×1′(25.4mm voice coil)，LF: 1×5′(38.5mm voice coil)；
Frequency Response: 116Hz～20KHz；
Power(Rms/Program/Peak): 100W/200W/400W；
Sensitivity: 90dB；
Impedance: 8Ω；
Maximum SPL: 110dB；
Directivity Angle: 120ºH×120ºV；
Speaker Input:NL4MP×2；
Size（H×W×D）：167*167*160 （mm）；
Size（H×W×D）：217×217×210（mm）；
Net Weight:3.3kg
