IQ-15

Single 15 "active speaker

It is equipped with a compact two-frequency speaker system with built-in power amplifier module, and adopts a long stroke high-power woofer unit. Built-in DSP processing chip, the advantage is that the medium frequency performance is thick and prominent, the use of high hardness wooden box material.

Product Characteristics

It is equipped with a compact two-frequency speaker system with built-in power amplifier module, and adopts a long stroke high-power woofer unit. Built-in DSP processing chip, the advantage is that the medium frequency performance is thick and prominent, the use of high hardness wooden box material. Suitable for large language reinforcement, music applications, small and medium performances. Application: Banquet hall, multi-function hall, auditorium, gymnasium, bar, shopping mall, mobile performance, public place

Parameter

System type:Single 15′ Full Range Speaker;

Drivers: HF:1×1.75′(44mm voice coil),LF: 1×15′(75mm voice coil);
Frequency Response: 75Hz~20KHz;
Power(Rms/Program/Peak): 350W/600W/1200W;
Sensitivity: 95dB;
Maximum SPL: 120dB;
Directivity Angle: 90ºH×55ºV;
Signal Input:2×XLR/TRS "combo jack" mic/line/Hi-Z guitar
Function:Bluetooth/USB/MP3
Product size(H×W×D):730×425×405(mm);
N.W:23kg

Page Content Update Time:2024-08-13 16:14:32

The relevant information on the website is for reference only. All products are subject to physical inspection and are subject to change without prior notice.
