Product Characteristics
■ Two-way design, high-efficiency unit configuration, strong intermediate frequency penetration, outstanding vocals
■HY series speakers are specially designed for conference halls, small performing arts venues, and places with high vocal requirements.
■ Low distortion, high definition, large sound pressure level, in order to achieve low distortion and high sound pressure level, two 5" woofers with φ100 magnet 35-core voice coil and a 1-inch horn tweeter,
■ The sound is clearer and softer, and the high-Q box design enables the 5" low-frequency unit to reach a low-frequency dive capability of 75Hz
Parameter
System type:Double 5′ Conference Speaker；
Drivers: HF:1×1.35′(34mm voice coil),LF: 2×5′(35.5mm voice coil)；
Frequency Response: 95Hz～16KHz；
Power(Rms/Program/Peak): 150W/300W/600W；
Sensitivity: 93dB；
Impedance: 8Ω；
Maximum SPL: 115dB；
Directivity Angle: 60ºH×30ºV；
Speaker Input:Terminal Block×1；
Product size（H×W×D）：438*178*208 （mm）；
Package size（H×W×D）：580*260*530（mm）；
N.W:8.5kg
G.W：kg
